STAINLESS STEEL 321 & 321 H BOLT is austenitic stainless steel. Titanium, on the other hand, helps to stabilize this stainless steel. The titanium component makes it more resistant to oxidation and corrosion. It can withstand temperatures of up to 1500 degrees Fahrenheit. Carbide precipitation is likely to occur at these high temperatures, but the inclusion of titanium prevents it.
The STAINLESS STEEL 321 & 321 H BOLT cannot be hardened sufficiently by heating, but it can be done by cold working. This also provides excellent welding capabilities. They are also very ductile and simple to fabricate. It can withstand harsh environments, but it is not suitable for chlorine-bound environments.
STAINLESS STEEL 321 & 321 H BOLT has high tensile strength and can withstand harsh environments such as aqueous environments. These bolts are widely used in applications requiring high strength because they can carry the weight while also preventing corrosion pitting and cracking.
The main distinction between 321 and 321 H stainless steel bolts is the amount of carbon in them. The carbon content of 321 bolts is approximately 0.08 percent, while the carbon content of 321 H is approximately 0.04 percent to 0.10 percent. Other elements such as manganese, silicon, phosphorus, sulfur, chromium, and nitrogen are also present.
| Specifications | DIN, ISO ,JIS ,GB, IS, BS, ASTM |
| Standard | ASTM A193 / ASME SA193 |
| Size | M0.2 to M33 | 3/6" to 2" | Custom Sizes |
| Length | 3 mm to 200 mm | Custom Sizes |
| Dimensions Standard | DIN: DIN931, 933, 934, 7991, 976, 125, 558,7968, 7990 ISO: ISO 4014, 4017, 4018, 4016 ASME B18.2.1, B18.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Test Certificate | As per EN 10204 / 3.1 Manufacturer Test Certificate, PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Raw materials Source | JSPL, Mukund Steel, Tata Steel, Dhamm Steel, Usha Martin,etc. |
| Packing | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating |
Cadmium Coating Hot Dipped Galvanizing Coating Ptfe Coated Phosphate Coating Teflon Coating Xylon Coating Zinc Coating |
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 321 | 1.4541 | S32100 | SUS 321 | X6CrNiTi18-10 |
| SS 321H | 1.4878 | S32109 | SUS 321H | X12CrNiTi18-9 |
| Grade | C | Mn | Si | P | S | Cr | N | Ni | Ti |
| SS 321 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 - 19.00 | 0.10 max | 9.00 - 12.00 | 5(C+N) – 0.70 max |
| SS 321H | 0.04 – 0.10 | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 - 19.00 | 0.10 max | 9.00 – 12.00 | 4(C+N) – 0.70 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1457 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| Stainless Steel Fasteners | Price In India(INR) | Price in UAE (Dirham) |
| Stainless Steel 321 Fastener | 744 - 1,2666 | 7.94 - 26.47 Dirham |
| Stainless Steel 321 Hex Bolt | 150 / peice | 7.94 Dirham |
| Stainless Steel 321h Nuts | 500 / peice | 26.47 Dirham |
